2025 MARVEL TILT FRAME BAND SAW MODEL: SERIES 8 MARK III - VT4555M

RECTANGULAR CAPACITY:
-CAPACITY NOMINAL ................... 18" X 22"
-CAPACITY 45 DEGREES RIGHT .......... 18" X 14.5"
-CAPACITY 45 DEGREES LEFT ........... 18" X 13"
-CAPACITY 60 DEGREES RIGHT .......... 18" X 9.7"
-CAPACITY 60 DEGREES LEFT ........... 18" X 7.3"
ROUND CAPACITY ...................... 18"
TILT ................................ 0 TO 60 DEGREES LEFT & RIGHT
BLADE SIZE .......................... 15'4" X 1.25" X 0.042"
BLADE SPEED RANGE ................... 50 TO 450 FPM
FEED PRESSURE INFINITELY VARIABLE ... 0 TO 250 LBS
WHEEL DIAMETERS ..................... 19"
SLOTTED WORK TABLE .................. 24.25" X 33"
TABLE HEIGHT ........................ 34.5"
APPROXIMATE SIZE .................... 72"W x 102"D x 90"H
APPROXIMATE WEIGHT .................. 3,000 LBS
