NEWWAY VNL-160HK Vertical CNC Lathe
Have one to sell?
ConditionUsed
1 available
NEWAY VNL-160HK VERTICAL CNC LATHE with FANUC 0i-TF PLUS CONTROL
3-color cycle light
12-tool magazine
Air Gun
Air conditioner electric cabinet
Automatic Lubricating System with pressure detection
Coolant System
Chip conveyor
Foundation kit includes leveling bolds and pads
German ZF 2-speed gearbox
Hydraulic system
LED Work light
Maintenance ladders
Operation manual
Operator platforms
Pneumatic System
Spindle chiller
Scrap cart
Water gun
Capacity
Max. Swing Diameter: 71’’ (1,800 mm)
Max. Turning Diameter: 63’’ (1,600 mm)
Max. Part Height: 63’’ (1,600 mm)
Max. Part Load 17,637 lb. (8,000 kg)
Table
Table diameter: 49’’ (1,250 mm)
Chuck type: 4 jaws manual
Max. Speed: 400 RPM
Spindle motor: 50 HP (37 KW)
2-speed gearbox
Max. torque: 12,061 ft-lb (16,330 NM)
Travel
X Axis: 39’’ (1,000 mm)
Z Axis: 31.5” (800 mm)
Elevating Cross rail: 35’’ (900 mm)
Tool Change
Tool Station: 12
Spindle Taper: BT50
Max. tool weight: 50 KG
Total weight capacity: 600 KG
Tool Size (turning tool): 32 x 32 mm OD shank
Feed Rate
X / Z-Axis Rapid: 473 / 393 IPM (12 / 10 m/min)
Cutting Feed Rates: 79 IPM (2 m/min)
General
Power: 220 Volts/ 3 Phase/ 60 Cycle / 60 KVA
Machine weight: 26,000 KG
Floor space (L x W x H): 20’ x 17’ x 17’
