Used 1998 W.F.WELLS F 16-2 | Horizontal Band Saws (Semi-Automatic)
Have one to sell?
ConditionUsed
1 available
Dual Column Horizontal, Semi-Automatic bandsaw, With Coolant system, Hydraulic pump, Blade tensioning, 1,1/4" blade
Coolant system, hydraulic blade tension, New blade and all available manuals
Capacity: Rectangular at 90° 16″ High x 20″ Wide, Round at 90° 16″ Diameter
Rectangular at 45° 16″ High X 9″ Wide, Round at 45° 9″ Diameter
Weight Capacity: 5,000 lbs
Blade Speed: 60-425 SFPM
Blade Size: 1¼” X .042″ X 15′
Blade Guide: Rollers and Carbide Side Blocks
Blade Tension: Hydraulic
Bandwheel Size: 20″
Vise: Full Stroke Hydraulic, 8-1/2”
Blade Drive: 7½ HP, AC Vector Drive
Sawing Force:0-750 lbs
Coolant Capacity:15 Gallons
Hydraulic Capacity: 20 Gallons
Hydraulic Drive: 2 HP Motor
Work Height: 26″
Shipping Weight: 2,450 lbs
Electrics: Wired to NFPA 79 Machine Tool Standards
Machine Dimensions: 97″ Length x 49″ Width x 83″ Height
Dual Column Horizontal, Semi-Automatic bandsaw, With Coolant system, Hydraulic pump, Blade tensioning, 1,1/4" blade
Coolant system, hydraulic blade tension, New blade and all available manuals
Imperial
| Rect-Cap (H) | 16" |
| Rect-Cap (W) | 20" |
| Rounds-Cap | 16" |
| Square-Cap | 16" |
| Power | 7.5 hp |
| Type (Auto, Manual, Semi) | Semi |
| Blade Width | 1.25" |
| Blade Thickness | 0.042" |
| Blade Length | 180" |
| Dimensions | 97″ Length x 49″ Width x 83″ Height |
| Weight | 2,450 Lbs. |
Capacity: Rectangular at 90° 16″ High x 20″ Wide, Round at 90° 16″ Diameter
Rectangular at 45° 16″ High X 9″ Wide, Round at 45° 9″ Diameter
Weight Capacity: 5,000 lbs
Blade Speed: 60-425 SFPM
Blade Size: 1¼” X .042″ X 15′
Blade Guide: Rollers and Carbide Side Blocks
Blade Tension: Hydraulic
Bandwheel Size: 20″
Vise: Full Stroke Hydraulic, 8-1/2”
Blade Drive: 7½ HP, AC Vector Drive
Sawing Force:0-750 lbs
Coolant Capacity:15 Gallons
Hydraulic Capacity: 20 Gallons
Hydraulic Drive: 2 HP Motor
Work Height: 26″
Shipping Weight: 2,450 lbs
Electrics: Wired to NFPA 79 Machine Tool Standards
Machine Dimensions: 97″ Length x 49″ Width x 83″ Height
