New
2022 ACRA ATEL1880C
Engine Lathes
10" 3-jaw, 12" 4-jaw Chucks, Steady rest, Follow rest, Coolant system, Halogen light, 4 way tool post, full length splash gaurd, Micro bed stop and manuals
Swing over bed 18"
Swing in gap 25"
Swing over cross slide 11"
Spindle Bore 3, 1/8"
Spindle Nose D1-8
Spindle speeds 16
Spindle RPM 20-1600 RPM
Spindel motor 12, 1/2 HP
Travel Cross slide 11"
Travel Compuond Slide 5, 3/8"
Inch Threads 45 Kinds 2-72 IPR
Metric Treads 39 kinds 0.2-14mm
Longitudunal feeds .0015"-.04" IPR
Cross feeds .00075-.02" IPR
Tail Stock Quill dia. 2, 5/16"
Quill travel 6, 1/2"
Quill taper #5M.T.
Voltage 220/440 AC 60 cycle 3 pahse
Length 130"
Width/ Height 48"/ 54"
Weight 6,000 lbs.
10" 3-jaw, 12" 4-jaw Chucks, Steady rest, Follow rest, Coolant system, Halogen light, 4 way tool post, full length splash gaurd, Micro bed stop and manuals
Swing over bed 18"
Swing in gap 25"
Swing over cross slide 11"
Spindle Bore 3, 1/8"
Spindle Nose D1-8
Spindle speeds 16
Spindle RPM 20-1600 RPM
Spindel motor 12, 1/2 HP
Travel Cross slide 11"
Travel Compuond Slide 5, 3/8"
Inch Threads 45 Kinds 2-72 IPR
Metric Treads 39 kinds 0.2-14mm
Longitudunal feeds .0015"-.04" IPR
Cross feeds .00075-.02" IPR
Tail Stock Quill dia. 2, 5/16"
Quill travel 6, 1/2"
Quill taper #5M.T.
Voltage 220/440 AC 60 cycle 3 pahse
Length 130"
Width/ Height 48"/ 54"
Weight 6,000 lbs.
