New
2022 ACRA 1700TE-3
Engine Lathes
10" 3-jaw, 12" 4-jaw Chucks, Steady rest, Follow rest, Coolant system, Halogen light, 4 way tool post/Holder, full length splash gaurds and manuals
OPTIONAL ACCESSORIES: PRICE
Face Plate…......................................................................................................................................... $ 600.00
Micro Bed Stop…................................................................................................................................ $ 300.00
Taper Attachment...................................................................................................................... $ 1,750.00
Taper Attachment Installation........................................................................................................ $ 425.00
Lever Type 5C Collet Closer JFK....................................................................................................... $ 1,400.00
Import Collect Closer (Taiwan).......................................................................................................... $ 1,200.00
Newall Digital Read-Out-10" X 60" DP700...................................................................................... $ 2,995.00
Newall Digital Read-Out-10" X 60NMS300..................................................................................... $ 1,850.00
Acu-Rite Digital Read-Out-10" X 60" 102......................................................................................... $ 2,550.00
Digital Read-Out-10" X 40" 200S................................................................................................... $ 2,900.00
Sony 10" X 60"....... ................................................................................................................... $ 2,545.00
D.R.O. Installation.............................................................................................................................. $ 250.00
Chuck Guard..................................................................................................... $ 350.00
Live Center MT 4.............................................................................................................. $ 100.00
EVS 460V....................................................................................................... $ 500.00
| Swing | 17" |
| Centers | 60" |
| Spindle Bore | 3.125" |
| Power | 10 hp |
| RPM | 0 RPM |
| Swing Over Cross Slide | 0" |
| Dimensions | 45" x 114" x 73" high |
| Weight | 4200 Lbs. |
Swing over bed 17"
Swing in gap 24-7/16"
Swing over cross slide 10-7/8"
Spindle Bore 3, 1/8"
Spindle Nose D1-8
Spindle Speeds 12
Spindle RPM 26- 1500 RPM
Spindel motor 10 HP
Travel Cross slide 9-84"
Travel Compuond Slide 5.9"
Inch Threads 45 Kinds 2-72 IPR
Metric Treads 39 kinds 0.2-14mm
Longitudunal feeds .0015"-.04" IPR
Cross feeds .00075-.02" IPR
Tail Stock Quill dia. 2.667"
Quill travel 5"
Quill taper #4 MT
Voltage 220/440 AC 60 cycle 3 pahse
Length 135"
Width/ Height 46" x 96" x 73" high
Weight 4,500 Lbs.
